- Australian GME Warranty
- 80 Channel UHF CB Radio
- Built-in GPS Receiver
- IP67 / MIL-STD 810G Rating
- OLED Speaker Microphone
- 2 Watt Front-Facing Speaker
- Bluetooth Connection
Overview
The XRS-390C is the first UHF CB radio to feature a built-in GPS receiver, offering true location awareness without relying on a smartphone to provide GPS location data. This capability is particularly useful in commercial applications where location tracking of users is required for workplace safety.
Featuring IP67 Ingress Protection and a MIL-STD810G rating, the XRS-390C is our toughest radio yet. Both the hideaway main unit and the rugged OLED speaker microphone are dust and waterproof, ensuring ultra-reliable performance in the toughest environments.
The XRS-390C has been designed and engineered to suit specific applications including UTVs and Agricultural machinery, À À bringing the full suite of unique XRSÀ¢âžÀ¢ Connect features to a new segment of the UHF CB market.
À À
GME - The Company
GME was established over 50 years ago with the intention of designing and manufacturing world-class radio and communication equipment within Australia. GME products fall under the umbrella of Standard Communications Pty. Ltd. and proudly remain a privately owned Australian company. Their radio products are of the most reliable quality and have been depended upon by the Australian rural community and State Emergency Services. Their communications product range is broader than just radios and we stock great quality GME products including marine and car audio, UHF and VHF radios, scanners, chargers, batteries and a host of communication accessories.
General
| Compliant Specification: | Meets AS/NZS 4365 for radio communications equipment in the UHF citizen and personal radio service |
| Frequency Range TX:À À | 476.425-477.4125 MHz |
| Number of Channels: | 80 |
| Channel Spacing:À À | 12.5 kHz |
| Operation Mode:À À | Simplex or half Duplex with repeater talk-around |
| Scanning Speed:À À | 20 ms per channel (50 channels per second) |
| Antenna Impedance:À À | 50 Ohms nominal |
| Nominal Battery Voltage: | 12 volts DC |
| Operating Voltage Range: | 10 - 16 volts DC |
| Battery Polarity:À À | Negative Earth |
| Standard Test Voltage: | 13.8 Volts DC |
| Over Voltage Protection: |
30 volts DC maximum. At 18 volts DC the channel display flashes À¢â ¬ÀŀHi DCÀ¢â ¬â ¢ for 5 seconds on receive. The RF power is reduced and TX flashes on transmit |
| Reverse Voltage Protection: |
Diode Crowbar |
| Over-current Protection: |
In-line 2 amp fuse |
| Operating Temperature: |
-10À À° C to +60À À°C |
À À
Transmitter
| RF Output | 5 watts |
| Spurious Emission:À À | < - 70 dBc |
| Frequency Error:À À | < À À± 1.5 kHz |
| Modulation: | FM |
| Maximum Deviation:À À | < À À± 2.5 kHz at + 20 Db AF limiting |
| Transmit Frequency Response:À À |
+6 dB per octave 300 Hz to 3 kHz + 1 . 3 dB |
| Demodulated Audio Signal to Noise: |
>45 dB unweighted |
| Current Consumption:À À | 1.7 amps with 50 Ohms termination |
À À
Receiver
| Intermediate Frequencies: |
38.85 MHz, 450 kHz |
| Sensitivity:À À | -122 dBm for 12 dB SINAD unweighted |
| Sensitivity:À À | -6 dB at À À± 3.5 kHz, -60 dB at À À± 12.5 kHz |
| Intermodulation Immunity:À À | -72 dB |
| Blocking Immunity:À À | -98 dB |
| Spurious Response Immunity:À À | 70 dB |
| Audio Output Power:À À | 3 watts average into 4 Ohms |
| Audio Signal to Noise:À À | >45 dB unweighted |
| Receive Frequency Response:À À | -6 dB/Octave de-emphasis 300 Hz to 3 kHz +1 -3 dB |
| Current Consumption:À À | <175 mA muted, 750 mA full volume |
| Conducted Spurious Emission:À À | <70 dBm |
À À
Mechanical Specifications
| Dimensions:À À | 29 (H) x 128 (L) x 92 (D) mm |
| Weight:À À | 310 Grams |
| 12 Volt Power Supply:À À | Two core cable with IP67 2 pin connection |
| Antenna:À À | FME panel socket |
| External Speaker:À À | 3.5 mm mono jack |
| Front Microphone Port:À À | 8 Pin RJ45 IP67 Connection |
